51101 Single Direction Trust Ball Bearing 12*26*9mm SUNBEARING

51101 Single Direction Trust Ball Bearing 12*26*9mm SUNBEARING

51101 Single Direction Trust Ball Bearing 12*26*9mm SUNBEARING
51101 Single Direction Trust Ball Bearing 12*26*9mm SUNBEARING51101 Single Direction Trust Ball Bearing 12*26*9mm SUNBEARING51101 Single Direction Trust Ball Bearing 12*26*9mm SUNBEARING51101 Single Direction Trust Ball Bearing 12*26*9mm SUNBEARING51101 Single Direction Trust Ball Bearing 12*26*9mm SUNBEARING
CategoriesThrust Ball Bearing
BrandSUNBEARING Rolling Bearing Manufacturer
Model51101
ColorSilver
FOB portDALIAN
Terms of PaymentL/C, Western Union, T/T, Paypal
Download DOCpdf icon
Update TimeMar 28,2024
Detail Information

51101 Single Direction Trust Ball Bearing 12*26*9mm SUNBEARING

   Product Description

51101 thrust ball bearing

Thrust ball bearing 51101

Specification

Design Units

Metric

Structure

Ball Bearing

Weights

0.021kgs

Cage Material

GCR 15, Stainless steel etc.

Material

GCR 15, Stainless steel etc.

Ball Type

Steel Ball

Seals Type

Open

Certificate

ISO9001:2008

Number of Row

Double

Dimensions

d-Bore Diameter

12mm

D-Outer Diameter

26mm

Precision Rating

P0 P2 P4 P5 P6

Clearance



C2 C3 C4 C5

H-Total Width

9mm

Basic Load Ratings

Cr Dynamic Load Rating

10400N

C0r Static Load Rating

15400N


Product Feature

1. Thrust ball bearing Equipped with one-way,two-way two types



 2. In order to allow installation error, either one-way or two-way, can choose spherical self-aligning spherical seat cushion type or with spherical seat type.



3. High quality steel - used can extend bearing life highest 80% super clean steel



4. The height of the grease technology -lubricants technology can make the life of the grease to extend and improve the performance of the bearing



5. The high grade ball - quiet and smooth when high-speed rotation



6. Use of options in the ring, can allow installation error.


Our Service

1.Customers' requirements are fully understood with abundant records made so that and customers' time can be saved.

2.We pay close attention to customers' drawings, submit them to our technicians and make correct replies.

3.We hunt for the most economical delivery service to reduce customers' cost.

4.We report the condition of production at any time to the customers.

5.After sale service is reliable and customers' feedbacks are considered seriously.

6.The latest market trend is always provided for our customers.



Application Field

1.Thrust Ball Bearings should use close to the radial bearing, in order to prevent the effect of shafts deflection.



2.When using big size ball bearings on a horizontal shaft, preload should be implemented to prevent the clearance between housing washer and balls.



3.Under the inevitable circumstances of shaft deflection and misalignment, aligning seat washer should be applied.
